Large ExcavatorsNon-Current
Overview
Cat large excavators range from 36 to 90 tons (36,000 to 90,000 kg). Their power, speed, and fuel efficiency make them exceptional choices for bulk earthmoving and heavy lifting applications. With powerful, yet efficient engines, advanced hydraulic systems, exclusive Cat Connect Technology, and a variety of Cat attachments, Cat large excavators can help you complete your large-scale projects on time and within budget.
Docs & Links
Products
336
- Net Power - ISO 9249
- —311 hp232 kW
- Operating Weight
- —81900 lb37200 kg
- Maximum Digging Depth
- —26.9 ft8200 mm
336 -Tier 4 / Stage V
- Net Power - ISO 9249
- —300 hp223.5 kW
- Operating Weight
- —81100 lb36800 kg
- Maximum Digging Depth
- —26.11 ft8210 mm
340 - Tier 4 / Stage V
- Net Power - ISO 9249
- —346 hp258.3 kW
- Operating Weight
- —83100 lb37700 kg
- Maximum Digging Depth
- —26.9 ft8210 mm
349
- Net Power - ISO 9249
- —424 hp316 kW
- Operating Weight
- —105200 lb47700 kg
- Maximum Digging Depth
- —25.1 ft7660 mm
350 - Tier 4 / Stage V
- Net Power - ISO 9249
- —413 hp308 kW
- Operating Weight
- —105100 lb46000 kg
- Maximum Digging Depth
- —26.11 ft8210 mm
352
- Net Power - ISO 9249
- —443 hp330 kW
- Operating Weight
- —107800 lb48900 kg
- Maximum Digging Depth
- —26.11 ft8210 mm
352F
- Net Power - ISO 9249
- —417 hp311 kW
- Operating Weight
- —112200 lb50900 kg
- Maximum Digging Depth
- —24.67 ft7510 mm
374F
- Net Power - ISO 9249
- —472 hp352 kW
- Operating Weight
- —161533 lb73270 kg
- Maximum Digging Depth
- —23.67 ft7220 mm
374 - Tier 4 / Stage V
- Net Power - ISO 9249
- —484 hp361 kW
- Operating Weight
- —162900 lb73890 kg
- Maximum Digging Depth
- —28.1 ft8570 mm
390F
- Net Power - ISO 9249
- —524 hp391 kW
- Operating Weight
- —198070 lb86840 kg
- Maximum Digging Depth
- —23.5 ft7160 mm
395 - Tier 4 / Stage V
- Net Power - ISO 9249
- —542 hp404 kW
- Operating Weight
- —207400 lb94000 kg
- Maximum Digging Depth
- —31.9 ft9670 mm
349F
- Net Power - ISO 9249
- —417 hp311 kW
- Operating Weight
- —107145 lb48600 kg
- Maximum Digging Depth
- —25.17 ft7660 mm
374F L
- Engine Model
- Cat C15 ACERT
- Net Flywheel Power
- —472 hp352 kW
- Operating Weight
- —157655 lb71511 kg
390F L
- Engine Model
- Cat C18 ACERT
- Net Flywheel Power
- —524 hp391 kW
- Operating Weight
- —192680 lb87400 kg
336D L
- Engine Model
- Cat® C9 ACERT™
- Net Flywheel Power
- —268 hp200 kW
- Operating Weight
- —80464 lb36498 kg
336D/D L Series 2
- Engine Model
- Cat® C9
- Net Flywheel Power
- —268 hp200 kW
- Operating Weight
- —81761 lb37086 kg
336E H Hybrid
- Engine Model
- Cat® C9.3 (ATAAC)
- Net Flywheel Power
- —286 hp213 kW
- Operating Weight
- —82000 lb37200 kg
336E L/LN
- Engine Model
- Cat® C9.3 (ATAAC)
- Net Flywheel Power
- —305 hp224 kW
- Operating Weight
- —85288 lb38686 kg
336F L
- Engine Model
- Cat® C9.3 (ATAAC)
- Net Flywheel Power
- —303 hp226 kW
- Operating Weight
- —88400 lb40100 kg
336F XE
- Engine Model
- Cat® C9.3 ACERT™
- Net Flywheel Power
- —306 hp228 kW
- Operating Weight
- —88800 lb40300 kg
336F L XE
- Engine Model
- Cat C9.3 ACERT
- Net Flywheel Power
- —306 hp228 kW
- Operating Weight
- —85100 lb38600 kg
345B L Series II
- Engine Model
- Cat 3176C ATAAC
- Net Flywheel Power
- —321 hp239 kW
- Maximum Travel Speed
- —2.73 mile/h4.4 km/h
345C L
- Engine Model
- Cat® C13 ACERT™
- Net Flywheel Power
- —345 hp257 kW
- Operating Weight
- —99150 lb44970 kg
345C/345C L
- Engine Model
- Cat® C13 ACERT™
- Net Flywheel Power
- —321 hp239 kW
- Operating Weight
- —99150 lb44970 kg
345D L
- Engine Model
- Cat® C13 ACERT™
- Net Flywheel Power
- —380 hp283 kW
- Operating Weight
- —100040 lb45375 kg
349D
- Engine Model
- Cat® C13 Diesel Engine with ACERT™ Technology
- Maximum Travel Speed
- —2.92 mile/h4.7 km/h
- Bore
- —5.12 in130 mm
349D L
- Engine Model
- Cat® C13 Diesel Engine with ACERT™ Technology
- Maximum Travel Speed
- —2.92 mile/h4.7 km/h
- Bore
- —5.12 in130 mm
349E
- Engine Model
- Cat® C13 ACERT™
- Net Flywheel Power
- —396 hp295 kW
- Operating Weight
- —117500 lb53300 kg
349F
- Engine Model
- Cat® C13 ACERT™
- Net Flywheel Power
- —396 hp295 kW
- Operating Weight
- —117500 lb53300 kg
349F L XE
- Engine Model
- Cat® C13 ACERT™
- Net Flywheel Power
- —417 hp311 kW
- Operating Weight
- —113600 lb51530 kg
349F L XE
- Engine Model
- Cat C13 ACERT
- Net Flywheel Power
- —408 hp304 kW
- Operating Weight
- —108300 lb49110 kg
352F
- Engine Model
- Cat® C13 ACERT™
- Net Flywheel Power
- —396 hp295 kW
- Operating Weight
- —115700 lb52500 kg
365B L
- Engine Model
- Cat 3196 ATAAC
- Net Flywheel Power
- —385 hp287 kW
- Maximum Travel Speed
- —2.6 mile/h4.1 km/h
365B L Series II
- Engine Model
- Caterpillar 3196 ATAAC
- Net Flywheel Power
- —404 hp302 kW
- Maximum Travel Speed
- —2.6 mile/h4.1 km/h
365C L
- Engine Model
- Cat® C15 ACERT™
- Net Flywheel Power
- —404 hp302 kW
- Operating Weight
- —145430 lb65960 kg
374F L
- Engine Model
- Cat® C15 ACERT™
- Net Flywheel Power
- —472 hp352 kW
- Operating Weight
- —165721 lb75170 kg
375
- Engine Model
- Cat 3406C Turbocharged ATAAC
- Net Flywheel Power
- —428 hp319 kW
- Maximum Travel Speed
- —2.7 mile/h4.4 km/h
375 L
- Engine Model
- Cat 3406C Turbocharged ATAAC
- Net Flywheel Power
- —428 hp319 kW
- Maximum Travel Speed
- —2.7 mile/h4.4 km/h
385B L
- Engine Model
- Caterpillar 3456 ATAAC
- Net Flywheel Power
- —513 hp382 kW
- Maximum Travel Speed
- —2.8 mile/h4.5 km/h
385B
- Engine Model
- Caterpillar 3456 ATAAC
- Net Flywheel Power
- —513 hp382 kW
- Maximum Travel Speed
- —2.8 mile/h4.5 km/h
| Model | Net Power - ISO 9249 | Operating Weight | Maximum Digging Depth |
|---|---|---|---|
| 336 | —311 hp232 kW | —81900 lb37200 kg | —26.9 ft8200 mm |
| 336 -Tier 4 / Stage V | —300 hp223.5 kW | —81100 lb36800 kg | —26.11 ft8210 mm |
| 340 - Tier 4 / Stage V | —346 hp258.3 kW | —83100 lb37700 kg | —26.9 ft8210 mm |
| 349 | —424 hp316 kW | —105200 lb47700 kg | —25.1 ft7660 mm |
| 350 - Tier 4 / Stage V | —413 hp308 kW | —105100 lb46000 kg | —26.11 ft8210 mm |
| 352 | —443 hp330 kW | —107800 lb48900 kg | —26.11 ft8210 mm |
| 352F | —417 hp311 kW | —112200 lb50900 kg | —24.67 ft7510 mm |
| 374F | —472 hp352 kW | —161533 lb73270 kg | —23.67 ft7220 mm |
| 374 - Tier 4 / Stage V | —484 hp361 kW | —162900 lb73890 kg | —28.1 ft8570 mm |
| 390F | —524 hp391 kW | —198070 lb86840 kg | —23.5 ft7160 mm |
| 395 - Tier 4 / Stage V | —542 hp404 kW | —207400 lb94000 kg | —31.9 ft9670 mm |
| 349F | —417 hp311 kW | —107145 lb48600 kg | —25.17 ft7660 mm |
| 374F L | — | —157655 lb71511 kg | — |
| 390F L | — | —192680 lb87400 kg | — |
| 336D L | —268 hp200 kW | —80464 lb36498 kg | — |
| 336D/D L Series 2 | — | —81761 lb37086 kg | — |
| 336E H Hybrid | — | —82000 lb37200 kg | — |
| 336E L/LN | — | —85288 lb38686 kg | — |
| 336F L | — | —88400 lb40100 kg | — |
| 336F XE | — | —88800 lb40300 kg | — |
| 336F L XE | — | —85100 lb38600 kg | — |
| 345B L Series II | —321 hp239 kW | — | — |
| 345C L | —345 hp257 kW | —99150 lb44970 kg | — |
| 345C/345C L | —321 hp239 kW | —99150 lb44970 kg | — |
| 345D L | —380 hp283 kW | —100040 lb45375 kg | — |
| 349D | — | — | — |
| 349D L | — | — | — |
| 349E | — | —117500 lb53300 kg | — |
| 349F | — | —117500 lb53300 kg | — |
| 349F L XE | — | —113600 lb51530 kg | — |
| 349F L XE | — | —108300 lb49110 kg | — |
| 352F | — | —115700 lb52500 kg | — |
| 365B L | — | — | — |
| 365B L Series II | —404 hp302 kW | — | — |
| 365C L | —404 hp302 kW | —145430 lb65960 kg | — |
| 374F L | — | —165721 lb75170 kg | — |
| 375 | —428 hp319 kW | — | — |
| 375 L | — | — | — |
| 385B L | —513 hp382 kW | — | — |
| 385B | —513 hp382 kW | — | — |
| 385C L | —513 hp382 kW | —187360 lb84980 kg | — |
| 390F L | — | —190204 lb86275 kg | — |
