Center-Pivot Backhoe LoadersNon-Current
Overview
Cat® Backhoe Highlights
- Spacious cab features ergonomic joystick controls with thumb-operated auxiliaries.
- Integrated Toolcarrier option for greater versatility with quick change forks, buckets, blades and brooms.
- Powerful hydraulic system for fine precision with high productivity.
- Travel speed of 25 mph (40 kph) to get between sites faster.
- Wide range of backhoe attachments including augers, hammers, compactors, and a factory-installed thumb.
- Ride control option for better material retention and a smoother ride.
Docs & Links
Products
415
- Net Power - SAE J1349:2011
- —70 hp52 kW
- Dig Depth - Standard
- —14 ft4277 mm
- Operating Weight - Maximum
- —24251 lb11000 kg
416C
- Net Power - SAE J1349:2011
- —75 hp56 kW
- Dig Depth - Standard
- —14.5 ft4420 mm
- Operating Weight - Maximum
- —21389 lb9700 kg
416D
- Net Power - SAE J1349:2011
- —74 hp55 kW
- Dig Depth - Standard
- —14.5 ft4390 mm
- Operating Weight - Maximum
- —21605 lb9800 kg
416E
- Net Power - SAE J1349:2011
- —87 hp65 kW
- Dig Depth - Standard
- —14.3 ft4360 mm
- Operating Weight - Maximum
- —22466 lb10200 kg
416F
- Net Power - SAE J1349:2011
- —87 hp65 kW
- Dig Depth - Standard
- —14.3 ft4360 mm
- Operating Weight - Maximum
- —24251 lb11000 kg
420D
- Net Power - SAE J1349:2011
- —85 hp63 kW
- Dig Depth - Standard
- —14.42 ft4390 mm
- Operating Weight - Maximum
- —21605 lb9800 kg
420E/420E IT
- Net Power - SAE J1349:2011
- —93 hp69 kW
- Dig Depth - Standard
- —14.3 ft4360 mm
- Operating Weight - Maximum
- —24251 lb11000 kg
420F/420F IT
- Net Power - SAE J1349:2011
- —93 hp69 kW
- Dig Depth - Standard
- —14.3 ft4360 mm
- Operating Weight - Maximum
- —24251 lb11000 kg
430D
- Net Power - SAE J1349:2011
- —94 hp70 kW
- Dig Depth - Standard
- —15.3 ft4639 mm
- Operating Weight - Maximum
- —21605 lb9800 kg
430E/430E IT
- Net Power - SAE J1349:2011
- —102 hp76 kW
- Dig Depth - Standard
- —15.41 ft4698 mm
- Operating Weight - Maximum
- —24251 lb11000 kg
430F/430F IT
- Net Power - SAE J1349:2011
- —107 hp80 kW
- Dig Depth - Standard
- —15.41 ft4698 mm
- Operating Weight - Maximum
- —24251 lb11000 kg
446B
- Net Power - SAE J1349:2011
- —102 hp76 kW
- Dig Depth - Standard
- —17.2 ft5219 mm
- Operating Weight - Maximum
- —19603.48 lb8892 kg
446D
- Net Power - SAE J1349:2011
- —101 hp75 kW
- Dig Depth - Standard
- —16.8 ft5142 mm
- Operating Weight - Maximum
- —25357 lb11500 kg
450E
- Net Power - SAE J1349:2011
- —124 hp92 kW
- Dig Depth - Standard
- —17.2 ft5260 mm
- Operating Weight - Maximum
- —27115 lb12300 kg
415F2
- Net Power - SAE J1349:2011
- —68 hp51 kW
- Dig Depth - Standard
- —14.3 ft4348 mm
- Operating Weight - Maximum
- —24251 lb11000 kg
415F2 IL
- Net Power - SAE J1349:2011
- —68 hp51 kW
- Operating Weight - Maximum
- —17637 lb8000 kg
- Cab - ROPS/FOPS
- —359 lb163 kg
416F2
- Net Power - SAE J1349:2011
- —87 hp65 kW
- Dig Depth - Standard
- —14.3 ft4348 mm
- Operating Weight - Maximum
- —24251 lb11000 kg
420F2/420F2 IT
- Net Power - SAE J1349:2011
- —93 hp69 kW
- Dig Depth - Standard
- —14.3 ft4360 mm
- Operating Weight - Maximum
- —24251 lb11000 kg
430F2/430F2 IT
- Net Power - SAE J1349:2011
- —108 hp80 kW
- Dig Depth - Standard
- —15.4 ft4686 mm
- Operating Weight - Maximum
- —24251 lb11000 kg
450F
- Net Power - SAE J1349:2011
- —127 hp95 kW
- Dig Depth - Standard
- —17.2 ft5260 mm
- Operating Weight - Maximum
- —27115 lb12300 kg
| Model | Net Power - SAE J1349:2011 | Dig Depth - Standard | Operating Weight - Maximum |
|---|---|---|---|
| 415 | —70 hp52 kW | —14 ft4277 mm | —24251 lb11000 kg |
| 416C | —75 hp56 kW | —14.5 ft4420 mm | —21389 lb9700 kg |
| 416D | —74 hp55 kW | —14.5 ft4390 mm | —21605 lb9800 kg |
| 416E | —87 hp65 kW | —14.3 ft4360 mm | —22466 lb10200 kg |
| 416F | —87 hp65 kW | —14.3 ft4360 mm | —24251 lb11000 kg |
| 420D | —85 hp63 kW | —14.42 ft4390 mm | —21605 lb9800 kg |
| 420E/420E IT | —93 hp69 kW | —14.3 ft4360 mm | —24251 lb11000 kg |
| 420F/420F IT | —93 hp69 kW | —14.3 ft4360 mm | —24251 lb11000 kg |
| 430D | —94 hp70 kW | —15.3 ft4639 mm | —21605 lb9800 kg |
| 430E/430E IT | —102 hp76 kW | —15.41 ft4698 mm | —24251 lb11000 kg |
| 430F/430F IT | —107 hp80 kW | —15.41 ft4698 mm | —24251 lb11000 kg |
| 446B | —102 hp76 kW | —17.2 ft5219 mm | —19603.48 lb8892 kg |
| 446D | —101 hp75 kW | —16.8 ft5142 mm | —25357 lb11500 kg |
| 450E | —124 hp92 kW | —17.2 ft5260 mm | —27115 lb12300 kg |
| 415F2 | —68 hp51 kW | —14.3 ft4348 mm | —24251 lb11000 kg |
| 415F2 IL | —68 hp51 kW | — | —17637 lb8000 kg |
| 416F2 | —87 hp65 kW | —14.3 ft4348 mm | —24251 lb11000 kg |
| 420F2/420F2 IT | —93 hp69 kW | —14.3 ft4360 mm | —24251 lb11000 kg |
| 430F2/430F2 IT | —108 hp80 kW | —15.4 ft4686 mm | —24251 lb11000 kg |
| 450F | —127 hp95 kW | —17.2 ft5260 mm | —27115 lb12300 kg |
