Small Wheel LoadersNon-Current
Overview
Cat® Small Wheel Loader Highlights
- Achieve hybrid like fuel efficiency with our intelligent hydrostatic power train through Standard Mode setting. For those tough and demanding applications, try the new Performance Mode feature. It allows you to boost power and hydraulic speed to get the job done quicker.
- Caterpillar's industry first Hystat™ Operator modes provides customizable power train settings to meet your application requirements and individual preferences.
- Work is made easy with the patented Performance Series buckets and optimized Z-bar linkage with parallel lift and high tilt forces allowing precise control of your loads.
- Fine tune machine performance with adjustments at your fingertips through the soft touch buttons and optional secondary display.
- Cat® C7.1 ACERT™ engine meets U.S. EPA Tier 4 Final/EU Stage IV emission standards.
Docs & Links
Products
926M
- Maximum Gross Power
- —168 hp125 kW
- Operating Weight
- —28193 lb12789 kg
- Bucket Capacities
- 1.9-5.0 m3 (2.5-6.5 yd3)
926M Aggregate Handler
- Maximum Gross Power
- —168 hp125 kW
- Operating Weight
- —28577 lb12963 kg
- Bucket Capacities
- 2.5-5.0 m3 (3.3-6.5 yd3)
930M
- Maximum Gross Power
- —168 hp125 kW
- Operating Weight
- —31382 lb14235 kg
- Bucket Capacities
- 2.1-5.0 m3 (2.7-6.5 yd3)
930M Ag Handler
- Maximum Gross Power
- —168 hp125 kW
- Operating Weight
- —31382 lb14235 kg
- Bucket Capacities
- 2.1-5.0 m³ (2.7-6.5 yd³)
930M Aggregate Handler
- Maximum Gross Power
- —168 hp125 kW
- Operating Weight
- —31848 lb14446 kg
- Bucket Capacities
- 2.5-5.0 m3 (3.3-6.5 yd3)
930M Waste Handler
- Maximum Gross Power
- —168 hp125 kW
- Operating Weight
- —37713 lb17107 kg
- Bucket Capacities
- 3.0-5.0 m3 (3.9-6.5 yd3)
938M
- Maximum Gross Power
- —188 hp140 kW
- Operating Weight
- —35778 lb16229 kg
- Bucket Capacities
- 2.5-5.0 m3 (3.2-6.5 yd3)
938M Aggregate Handler
- Maximum Gross Power
- —188 hp140 kW
- Operating Weight
- —36839 lb16710 kg
- Bucket Capacities
- 2.9-5.0 m3 (3.8-6.5 yd3)
938M Waste Handler
- Maximum Gross Power
- —188 hp140 kW
- Operating Weight
- —41794 lb18958 kg
- Bucket Capacities
- 3.0-5.0 m3 (3.9-6.5 yd3)
926M Waste Handler
- Maximum Gross Power
- —168 hp125 kW
- Operating Weight
- —34600 lb15695 kg
- Bucket Capacities
- 3.0-5.0 m³ (3.9-6.5 yd³)
924Gz
- Rated Net Power
- —129 hp96 kW
- Operating Weight
- —23920 lb10850 kg
- Bucket Capacities
- 1.7 m3 - 2.1 m3 2.2 yd3 - 2.7 yd3
924H
- Rated Net Power
- —128 hp96 kW
- Operating Weight
- —25644 lb11632 kg
- Bucket Capacities
- 1.7 m3 - 2.8 m3 2.2 yd3 - 3.6 yd3
924Hz
- Rated Net Power
- —128 hp96 kW
- Operating Weight
- —24180 lb10968 kg
- Bucket Capacities
- 1.7 m3 - 2.1 m3 2.2 yd3 - 2.7 yd3
924K
- Rated Net Power
- —141 hp105 kW
- Operating Weight
- —28360 lb12868 kg
- Bucket Capacities
- 1.9 m3 - 5.0 m3 2.5 yd3 - 6.5 yd3
928G
- Rated Net Power
- —143 hp107 kW
- Operating Weight
- —27140 lb12310 kg
- Bucket Capacities
- 1.9 m3 - 2.3 m3 2.5 yd3 - 3.0 yd3
928Gz
- Rated Net Power
- —143 hp107 kW
- Operating Weight
- —27140 lb12310 kg
- Bucket Capacities
- 2.0 m3 - 2.3 m3 2.6 yd3 - 3.0 yd3
928Hz
- Rated Net Power
- —149 hp111 kW
- Operating Weight
- —27699 lb12564 kg
- Bucket Capacities
- 2.0 m3 - 2.3 m3 2.6 yd3 - 3.0 yd3
930G
- Rated Net Power
- —149 hp111 kW
- Operating Weight
- —28725 lb13029 kg
- Bucket Capacities
- 2.1 m3 - 5.0 m3 2.6 yd3 - 6.5 yd3
930H
- Rated Net Power
- —149 hp111 kW
- Operating Weight
- —28725 lb13029 kg
- Bucket Capacities
- 2.1 m3 - 5.0 m3 2.6 yd3 - 6.5 yd3
930K
- Rated Net Power
- —154 hp115 kW
- Operating Weight
- —30479 lb13829 kg
- Bucket Capacities
- 2.1 m3 - 5.0 m3 2.7 yd3 - 6.5 yd3
| Model | Maximum Gross Power | Operating Weight | Bucket Capacities |
|---|---|---|---|
| 926M | —168 hp125 kW | —28193 lb12789 kg | 1.9-5.0 m3 (2.5-6.5 yd3) |
| 926M Aggregate Handler | —168 hp125 kW | —28577 lb12963 kg | 2.5-5.0 m3 (3.3-6.5 yd3) |
| 930M | —168 hp125 kW | —31382 lb14235 kg | 2.1-5.0 m3 (2.7-6.5 yd3) |
| 930M Ag Handler | —168 hp125 kW | —31382 lb14235 kg | 2.1-5.0 m³ (2.7-6.5 yd³) |
| 930M Aggregate Handler | —168 hp125 kW | —31848 lb14446 kg | 2.5-5.0 m3 (3.3-6.5 yd3) |
| 930M Waste Handler | —168 hp125 kW | —37713 lb17107 kg | 3.0-5.0 m3 (3.9-6.5 yd3) |
| 938M | —188 hp140 kW | —35778 lb16229 kg | 2.5-5.0 m3 (3.2-6.5 yd3) |
| 938M Aggregate Handler | —188 hp140 kW | —36839 lb16710 kg | 2.9-5.0 m3 (3.8-6.5 yd3) |
| 938M Waste Handler | —188 hp140 kW | —41794 lb18958 kg | 3.0-5.0 m3 (3.9-6.5 yd3) |
| 926M Waste Handler | —168 hp125 kW | —34600 lb15695 kg | 3.0-5.0 m³ (3.9-6.5 yd³) |
| 924F | — | —20081 lb9100 kg | — |
| 924Gz | — | — | — |
| 924Gz | — | —23920 lb10850 kg | 1.7 m3 - 2.1 m3 2.2 yd3 - 2.7 yd3 |
| 924H | — | —25644 lb11632 kg | 1.7 m3 - 2.8 m3 2.2 yd3 - 3.6 yd3 |
| 924Hz | — | —24180 lb10968 kg | 1.7 m3 - 2.1 m3 2.2 yd3 - 2.7 yd3 |
| 924K | — | —28360 lb12868 kg | 1.9 m3 - 5.0 m3 2.5 yd3 - 6.5 yd3 |
| 928G | — | — | — |
| 928G | — | —27140 lb12310 kg | 1.9 m3 - 2.3 m3 2.5 yd3 - 3.0 yd3 |
| 928Gz | — | —27140 lb12310 kg | 2.0 m3 - 2.3 m3 2.6 yd3 - 3.0 yd3 |
| 928Hz | — | —27699 lb12564 kg | 2.0 m3 - 2.3 m3 2.6 yd3 - 3.0 yd3 |
| 930G | — | —28725 lb13029 kg | 2.1 m3 - 5.0 m3 2.6 yd3 - 6.5 yd3 |
| 930H | — | —28725 lb13029 kg | 2.1 m3 - 5.0 m3 2.6 yd3 - 6.5 yd3 |
| 930K | — | —30479 lb13829 kg | 2.1 m3 - 5.0 m3 2.7 yd3 - 6.5 yd3 |
| 938G | — | — | — |
| 938G Series II | — | — | — |
| 938H | — | —33190 lb15059 kg | 2.3 m3 - 3.0 m3 3.0 yd3 - 4.0 yd3 |
| 938K | — | —35104 lb15928 kg | 2.5 m3 - 5.0 m3 3.2 yd3 - 6.5 yd3 |
| IT14G | — | — | — |
| IT24F | — | —22021.95 lb9989 kg | — |
| IT28G | — | —26526 lb12030 kg | — |
| IT28G | — | — | — |
Benefits & Features
Data not available.
