Industrial Diesel Engines

Overview
Benefits & Features

Overview

Perkins power solutions are designed to improve your performance and productivity. We have poured our passion, innovation and engineering excellence into manufacturing more than 22 million engines - 5 million of which are are still powering the world, and our customers, today.

Products

Units:

402D-05

Maximum Power: —13.7 HP10.2 kW
Maximum Torque: —21.9 lb-ft @ 2600 rpm29.7 Nm @ 2600 rpm
Emissions: U.S. EPA Tier 4 Interim equivalent

402J-05

Maximum Power: —11.8 HP8.8 kW
Maximum Torque: —22 lb-ft @ 2100 rpm29.7 Nm @ 2100 rpm
Emissions: EU Stage V

403F-07

Maximum Power: —11.8 HP8.8 kW
Maximum Torque: —30.2 lb-ft @ 2000 rpm41 Nm @ 2000 rpm
Emissions: U.S EPA Tier 4 Final

403J-07

Maximum Power: —17.8 HP13.3 kW
Maximum Torque: —32 lb-ft @ 2400 rpm44 Nm @ 2400 rpm
Emissions: EU Stage V

403D-07

Maximum Power: —20.5 HP15.3 kW
Maximum Torque: —37.1 lb-ft @ 2400 rpm50.4 Nm @ 2400 rpm
Emissions: EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent

403J-11

Maximum Power: —24 HP18.4 kW
Maximum Torque: —49 lb-ft @ 2100 rpm66.8 Nm @ 2100 rpm
Emissions: EU Stage V, U.S. Tier 4 Final

403J-11T

Maximum Power: —24 HP18.4 kW
Maximum Torque: —63.4 lb-ft @ 1600 rpm86 Nm @ 1600 rpm
Emissions: EU Stage V, U.S. EPA Tier 4 Final

403EA-11

Maximum Power: —28 HP21 kW
Maximum Torque: —52 lb-ft @ 1800 rpm70 Nm @ 1800 rpm
Emissions: China NR IV

403EA-11T

Maximum Power: —24 HP18.4 kW
Maximum Torque: —63.4 lb-ft @ 1600 rpm86 Nm @ 1600 rpm
Emissions: China NR IV

403D-11

Maximum Power: —28.2 HP21 kW
Maximum Torque: —49.4 lb-ft @ 2400 rpm67 Nm @ 2400 rpm
Emissions: EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent, China NRIII

403F-15

Maximum Power: —24.6 HP18.4 kW
Maximum Torque: —63.4 lb-ft @ 1800 rpm86 Nm @ 1800 rpm
Emissions: U.S EPA Tier 4 Final

403D-15

Maximum Power: —33.7 HP25.1 kW
Maximum Torque: —70.8 lb-ft @ 1800 rpm96 Nm @ 1800 rpm
Emissions: EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent, China NRIII

403D-15T

Maximum Power: —40.2 HP30 kW
Maximum Torque: —82.4 lb-ft @ 1800 rpm111.8 Nm @ 1800 rpm
Emissions: EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent, China NRIII

403J-17

Maximum Power: —24 HP18.9 kW
Maximum Torque: —75.7 lb-ft @ 1400 rpm97.9 Nm @ 1400 rpm
Emissions: EU Stage V, U.S. EPA Tier 4 Final

403J-17T

Maximum Power: —25 HP18.9 kW
Maximum Torque: —76 lb-ft @ 1600 rpm103 Nm @ 1600 rpm
Emissions: EU Stage V, U.S. EPA Tier 4 Final

403EA-17

Maximum Power: —25.3 HP18.9 kW
Maximum Torque: —75.7 lb-ft @ 1400 rpm97.9 Nm @ 1400 rpm
Emissions: China NR IV

403J-E17T

Maximum Power: —48 HP36 kW
Maximum Torque: —122 lb-ft @ 1600 rpm166 Nm @ 1600 rpm
Emissions: EU Stage V, U.S. EPA Tier 4 Final

404J-E22T

Maximum Power: —60 HP45 kW
Maximum Torque: —164 lb-ft @ 1600 rpm222 Nm @ 1600 rpm
Emissions: EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4

404J-E22TA

Maximum Power: —74 HP55 kW
Maximum Torque: —199 lb-ft @ 1600 rpm270 Nm @ 1600 rpm
Emissions: EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4

404EA-22

Maximum Power: —48 HP36 kW
Maximum Torque: —105.2 lb-ft @ 1800 rpm142.7 Nm @ 1800 rpm
Emissions: China NR IV

404D-22

Maximum Power: —51 HP38 kW
Maximum Torque: —105.2 lb-ft @ 1800 rpm142.7 Nm @ 1800 rpm
Emissions: EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent, China NRIII

404D-22T

Maximum Power: —61 HP45.5 kW
Maximum Torque: —139.5 lb-ft @ 1800 rpm189.1 Nm @ 1800 rpm
Emissions: EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent

404D-22TA

Maximum Power: —66 HP49.2 kW
Maximum Torque: —147.5 lb-ft @ 1800 rpm200 Nm @ 1800 rpm
Emissions: EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent

904J-E28T

Maximum Power: —74 HP55 kW
Maximum Torque: —221 lb-ft @ 1600 rpm300 Nm @ 1600 rpm
Emissions: EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4

904J-E28TA

Maximum Power: —74 HP55 kW
Maximum Torque: —280 lb-ft @ 1360 rpm380 Nm @ 1360 rpm
Emissions: EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4

904D-E28T

Maximum Power: —74 HP55 kW
Maximum Torque: —221 lb-ft @ 1600 rpm300 Nm @ 1600 rpm
Emissions: UN ECE R96 Stage IIIA, Brazil MAR-1

904J-E36TA

Maximum Power: —134 HP100 kW
Maximum Torque: —406 lb-ft @ 1500 rpm550 Nm @ 1500 rpm
Emissions: EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4

904J-E36TA for Tractors

Maximum Power: —134 HP100 kW
Maximum Torque: —391 lb-ft @ 1500 rpm530 Nm @ 1500 rpm
Emissions: EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4

904EA-E36TA

Maximum Power: —110 HP82 kW
Maximum Torque: —332 lb-ft @ 1500 rpm450 Nm @ 1500 rpm
Emissions: China NR IV

904D-E36TA

Maximum Power: —121 HP90 kW
Maximum Torque: —369 lb-ft @ 1500 rpm500 Nm @ 1500 rpm
Emissions: UN ECE R96 Stage IIIA, Brazil MAR-1

904D-E36TA for Tractors

Maximum Power: —121 HP90 kW
Maximum Torque: —369 lb-ft @ 1500 rpm500 Nm @ 1500 rpm
Emissions: UN ECE R96 Stage IIIA, Brazil MAR-1

1103D-33

Maximum Power: —49.5 HP36.9 kW
Maximum Torque: —139.3 lb-ft @ 1400 rpm189 Nm @ 1400 rpm
Emissions: UN ECE R96 Stage IIIA

1103D-33TA

Maximum Power: —77.8 HP58 kW
Maximum Torque: —228.6 lb-ft @ 1400 rpm310 Nm @ 1400 rpm
Emissions: UN ECE R96 Stage IIIA

1103C-33T

Maximum Power: —74 HP55 kW
Maximum Torque: —215 lb-ft @ 1400 rpm291 Nm @ 1400 rpm
Emissions: EU Stage II/U.S. EPA Tier 2 equivalent

1104D-44

Maximum Power: —75 HP55.9 kW
Maximum Torque: —195 lb-ft @ 1700 rpm265 Nm @ 1700 rpm
Emissions: UN ECE R96 Stage IIIA, China Nonroad Stage III

1104D-44T

Maximum Power: —99.9 HP74.5 kW
Maximum Torque: —289 lb-ft @ 1400 rpm392 Nm @ 1400 rpm
Emissions: UN ECE R96 Stage IIIA, China Nonroad Stage III

1104D-44TA

Maximum Power: —111.3 HP83 kW
Maximum Torque: —308 lb-ft @ 1400 rpm418 Nm @ 1400 rpm
Emissions: UN ECE R96 Stage IIIA, China Nonroad Stage III

1104D-E44T

Maximum Power: —100 HP74.5 kW
Maximum Torque: —310 lb-ft @ 1400 rpm420 Nm @ 1400 rpm
Emissions: UN ECE R96 Stage IIIA, China Nonroad Stage III

1104D-E44TA

Maximum Power: —142 HP106 kW
Maximum Torque: —411.2 lb-ft @ 1400 rpm558 Nm @ 1400 rpm
Emissions: UN ECE R96 Stage IIIA, China Nonroad Stage III, Brazil MAR-1

1104C-44

Maximum Power: —85.8 HP64 kW
Maximum Torque: —227 lb-ft @ 1200 rpm308 Nm @ 1200 rpm
Emissions: EU Stage II/U.S. EPA Tier 2 equivalent

1104C-44T

Maximum Power: —99.9 HP74.5 kW
Maximum Torque: —306 lb-ft @ 1350 rpm415 Nm @ 1350 rpm
Emissions: EU Stage II/U.S. EPA Tier 2 equivalent

1104C-44TA

Maximum Power: —130.1 HP97 kW
Maximum Torque: —369 lb-ft @ 1400 rpm500 Nm @ 1400 rpm
Emissions: EU Stage II/U.S. EPA Tier 2 equivalent

1104A-44

Maximum Power: —85 HP63.5 kW
Maximum Torque: —216 lb-ft @ 1200 rpm293 Nm @ 1200 rpm
Emissions: Non-Certified

1104A-44T

Maximum Power: —108 HP80.5 kW
Maximum Torque: —298 lb-ft @ 1400 rpm404 Nm @ 1400 rpm
Emissions: Non-Certified

1106D-70TA

Maximum Power: —173 HP129 kW
Maximum Torque: —553 lb-ft @ 1300 rpm750 Nm @ 1300 rpm
Emissions: UN ECE R96 Stage IIIA

1106D-E70TA

Maximum Power: —274.9 HP205 kW
Maximum Torque: —774.4 lb-ft @ 1400 rpm1050 Nm @ 1400 rpm
Emissions: UN ECE R96 Stage IIIA, Brazil MAR-1, China NRIII

1106C-70TA

Maximum Power: —217 HP162 kW
Maximum Torque: —663 lb-ft @ 1400 rpm900 Nm @ 1400 rpm
Emissions: EU Stage II/U.S. EPA Tier 2 equivalent

1204J-E44TA

Maximum Power: —148 HP110 kW
Maximum Torque: —413 lb-ft @ 1400 rpm560 Nm @ 1400 rpm
Emissions: EU Stage V, U.S. EPA & CARB Tier 4 Final

1204EA-E44TA

Maximum Power: —148 HP110 kW
Maximum Torque: —413 lb-ft @ 1400 rpm560 Nm @ 1400 rpm
Emissions: China NR IV

1204J-E44TTA

Maximum Power: —200 HP150 kW
Maximum Torque: —609 lb-ft @ 1400 rpm825 Nm @ 1400 rpm
Emissions: EU Stage V, U.S. EPA Tier 4 Final

1204EA-E44TTA

Maximum Power: —173 HP129 kW
Maximum Torque: —553 lb-ft @ 1400 rpm750 Nm @ 1400 rpm
Emissions: China NR IV

1206J-E70TA

Maximum Power: —202 HP151 kW
Maximum Torque: —642 lb-ft @ 1400 rpm870 Nm @ 1400 rpm
Emissions: EU Stage V, U.S Tier 4 Final

1206EA-E70TA

Maximum Power: —202 HP151 kW
Maximum Torque: —642 lb-ft @ 1400 rpm870 Nm @ 1400 rpm
Emissions: China NR IV

1206J-E70TTA

Maximum Power: —320 HP239 kW
Maximum Torque: —935 lb-ft @ 1400 rpm1282 Nm @ 1400 rpm
Emissions: EU Stage V, U.S. EPA & CARB Tier 4 Final

1206EA-E70TTA

Maximum Power: —302 HP225 kW
Maximum Torque: —940 lb-ft @ 1400 rpm1274 Nm @ 1400 rpm
Emissions: China NR IV

1706J-E93TA

Maximum Power: —456 HP340 kW
Maximum Torque: —1540 lb-ft @ 1400 rpm2088 Nm @ 1400 rpm
Emissions: EU Stage V, U.S. EPA Tier 4 Final, Korea Stage V, Japan 2014

1706EA-E93TA

Maximum Power: —456 HP340 kW
Maximum Torque: —1540 lb-ft @ 1400 rpm2088 Nm @ 1400 rpm
Emissions: China Nonroad Stage IV

1706D-E93TA

Maximum Power: —416 HP310 kW
Maximum Torque: —1335 lb-ft @ 1400 rpm1810 Nm @ 1400 rpm
Emissions: China Nonroad Stage III, Brazil MAR-1, UN ECE R96 Stage IIIA

2206D-E13TA

Maximum Power: —536 HP400 kW
Maximum Torque: —1735 lb-ft @ 1400 rpm2353 Nm @ 1400 rpm
Emissions: China Nonroad Stage III, Brazil MAR-1, UN ECE R96 Stage IIIA, U.S. EPA Tier 3

2406J-E13TA

Maximum Power: —577 HP430 kW
Maximum Torque: —1943 lb-ft @ 1400 rpm2634 Nm @ 1400 rpm
Emissions: EU Stage V, U.S. EPA Tier 4 Final, Japan 2014, Korea tier 4 Final

2406EA-E13TA

Maximum Power: —577 HP430 kW
Maximum Torque: —1943 lb-ft @ 1400 rpm2634 Nm @ 1400 rpm
Emissions: China NR IV

2506J-E15TA

Maximum Power: —581 HP433 kW
Maximum Torque: —1958 lb-ft @ 1400 rpm2655 Nm @ 1400 rpm
Emissions: EU Stage V, U.S. EPA & CARB Tier 4 Final

2506EA-E15TA

Maximum Power: —580 HP433 kW
Maximum Torque: —1958 lb-ft @ 1400 rpm2655 Nm @ 1400 rpm
Emissions: China NR IV

2506D-E15TA

Maximum Power: —595 HP444 kW
Maximum Torque: —2004 lb-ft @ 1400 rpm2717 Nm @ 1400 rpm
Emissions: EU Stage IIIA/U.S. EPA Tier 3, China NRIII

2806J-E18TA

Maximum Power: —630 HP470 kW
Maximum Torque: —2178 lb-ft @ 1400 rpm2953 Nm @ 1400 rpm
Emissions: EU Stage V

2806EA-E18TA

Maximum Power: —630 HP470 kW
Maximum Torque: —2177 lb-ft @ 1300 rpm2951 Nm @ 1300 rpm
Emissions: China NR IV

2806J-E18TTA

Maximum Power: —800 HP597 kW
Maximum Torque: —2734 lb-ft @ 1400 rpm3710 Nm @ 1300 rpm
Emissions: EU Stage V, U.S. EPA Tier 4 Final

2806D-E18TA

Maximum Power: —630 HP470 kW
Maximum Torque: —2043 lb-ft @ 1400 rpm2769 Nm @ 1400 rpm
Emissions: UN ECE R96 Stage IIIA, China NRIII

2806D-E18TTA

Maximum Power: —800 HP597 kW
Maximum Torque: —2697 lb-ft @ 1400 rpm3656 Nm @ 1400 rpm
Emissions: UN ECE R96 Stage IIIA, China NRIII

Model	Maximum Power	Maximum Torque	Emissions
402D-05	—13.7 HP10.2 kW	—21.9 lb-ft @ 2600 rpm29.7 Nm @ 2600 rpm	U.S. EPA Tier 4 Interim equivalent
402J-05	—11.8 HP8.8 kW	—22 lb-ft @ 2100 rpm29.7 Nm @ 2100 rpm	EU Stage V
403F-07	—11.8 HP8.8 kW	—30.2 lb-ft @ 2000 rpm41 Nm @ 2000 rpm	U.S EPA Tier 4 Final
403J-07	—17.8 HP13.3 kW	—32 lb-ft @ 2400 rpm44 Nm @ 2400 rpm	EU Stage V
403D-07	—20.5 HP15.3 kW	—37.1 lb-ft @ 2400 rpm50.4 Nm @ 2400 rpm	EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent
403J-11	—24 HP18.4 kW	—49 lb-ft @ 2100 rpm66.8 Nm @ 2100 rpm	EU Stage V, U.S. Tier 4 Final
403J-11T	—24 HP18.4 kW	—63.4 lb-ft @ 1600 rpm86 Nm @ 1600 rpm	EU Stage V, U.S. EPA Tier 4 Final
403EA-11	—28 HP21 kW	—52 lb-ft @ 1800 rpm70 Nm @ 1800 rpm	China NR IV
403EA-11T	—24 HP18.4 kW	—63.4 lb-ft @ 1600 rpm86 Nm @ 1600 rpm	China NR IV
403D-11	—28.2 HP21 kW	—49.4 lb-ft @ 2400 rpm67 Nm @ 2400 rpm	EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent, China NRIII
403F-15	—24.6 HP18.4 kW	—63.4 lb-ft @ 1800 rpm86 Nm @ 1800 rpm	U.S EPA Tier 4 Final
403D-15	—33.7 HP25.1 kW	—70.8 lb-ft @ 1800 rpm96 Nm @ 1800 rpm	EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent, China NRIII
403D-15T	—40.2 HP30 kW	—82.4 lb-ft @ 1800 rpm111.8 Nm @ 1800 rpm	EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent, China NRIII
403J-17	—24 HP18.9 kW	—75.7 lb-ft @ 1400 rpm97.9 Nm @ 1400 rpm	EU Stage V, U.S. EPA Tier 4 Final
403J-17T	—25 HP18.9 kW	—76 lb-ft @ 1600 rpm103 Nm @ 1600 rpm	EU Stage V, U.S. EPA Tier 4 Final
403EA-17	—25.3 HP18.9 kW	—75.7 lb-ft @ 1400 rpm97.9 Nm @ 1400 rpm	China NR IV
403J-E17T	—48 HP36 kW	—122 lb-ft @ 1600 rpm166 Nm @ 1600 rpm	EU Stage V, U.S. EPA Tier 4 Final
404J-E22T	—60 HP45 kW	—164 lb-ft @ 1600 rpm222 Nm @ 1600 rpm	EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4
404J-E22TA	—74 HP55 kW	—199 lb-ft @ 1600 rpm270 Nm @ 1600 rpm	EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4
404EA-22	—48 HP36 kW	—105.2 lb-ft @ 1800 rpm142.7 Nm @ 1800 rpm	China NR IV
404D-22	—51 HP38 kW	—105.2 lb-ft @ 1800 rpm142.7 Nm @ 1800 rpm	EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent, China NRIII
404D-22T	—61 HP45.5 kW	—139.5 lb-ft @ 1800 rpm189.1 Nm @ 1800 rpm	EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent
404D-22TA	—66 HP49.2 kW	—147.5 lb-ft @ 1800 rpm200 Nm @ 1800 rpm	EU Stage IIIA/U.S. EPA Tier 4 Interim equivalent
904J-E28T	—74 HP55 kW	—221 lb-ft @ 1600 rpm300 Nm @ 1600 rpm	EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4
904J-E28TA	—74 HP55 kW	—280 lb-ft @ 1360 rpm380 Nm @ 1360 rpm	EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4
904D-E28T	—74 HP55 kW	—221 lb-ft @ 1600 rpm300 Nm @ 1600 rpm	UN ECE R96 Stage IIIA, Brazil MAR-1
904J-E36TA	—134 HP100 kW	—406 lb-ft @ 1500 rpm550 Nm @ 1500 rpm	EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4
904J-E36TA for Tractors	—134 HP100 kW	—391 lb-ft @ 1500 rpm530 Nm @ 1500 rpm	EU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4
904EA-E36TA	—110 HP82 kW	—332 lb-ft @ 1500 rpm450 Nm @ 1500 rpm	China NR IV
904D-E36TA	—121 HP90 kW	—369 lb-ft @ 1500 rpm500 Nm @ 1500 rpm	UN ECE R96 Stage IIIA, Brazil MAR-1
904D-E36TA for Tractors	—121 HP90 kW	—369 lb-ft @ 1500 rpm500 Nm @ 1500 rpm	UN ECE R96 Stage IIIA, Brazil MAR-1
1103D-33	—49.5 HP36.9 kW	—139.3 lb-ft @ 1400 rpm189 Nm @ 1400 rpm	UN ECE R96 Stage IIIA
1103D-33TA	—77.8 HP58 kW	—228.6 lb-ft @ 1400 rpm310 Nm @ 1400 rpm	UN ECE R96 Stage IIIA
1103C-33T	—74 HP55 kW	—215 lb-ft @ 1400 rpm291 Nm @ 1400 rpm	EU Stage II/U.S. EPA Tier 2 equivalent
1104D-44	—75 HP55.9 kW	—195 lb-ft @ 1700 rpm265 Nm @ 1700 rpm	UN ECE R96 Stage IIIA, China Nonroad Stage III
1104D-44T	—99.9 HP74.5 kW	—289 lb-ft @ 1400 rpm392 Nm @ 1400 rpm	UN ECE R96 Stage IIIA, China Nonroad Stage III
1104D-44TA	—111.3 HP83 kW	—308 lb-ft @ 1400 rpm418 Nm @ 1400 rpm	UN ECE R96 Stage IIIA, China Nonroad Stage III
1104D-E44T	—100 HP74.5 kW	—310 lb-ft @ 1400 rpm420 Nm @ 1400 rpm	UN ECE R96 Stage IIIA, China Nonroad Stage III
1104D-E44TA	—142 HP106 kW	—411.2 lb-ft @ 1400 rpm558 Nm @ 1400 rpm	UN ECE R96 Stage IIIA, China Nonroad Stage III, Brazil MAR-1
1104C-44	—85.8 HP64 kW	—227 lb-ft @ 1200 rpm308 Nm @ 1200 rpm	EU Stage II/U.S. EPA Tier 2 equivalent
1104C-44T	—99.9 HP74.5 kW	—306 lb-ft @ 1350 rpm415 Nm @ 1350 rpm	EU Stage II/U.S. EPA Tier 2 equivalent
1104C-44TA	—130.1 HP97 kW	—369 lb-ft @ 1400 rpm500 Nm @ 1400 rpm	EU Stage II/U.S. EPA Tier 2 equivalent
1104A-44	—85 HP63.5 kW	—216 lb-ft @ 1200 rpm293 Nm @ 1200 rpm	Non-Certified
1104A-44T	—108 HP80.5 kW	—298 lb-ft @ 1400 rpm404 Nm @ 1400 rpm	Non-Certified
1106D-70TA	—173 HP129 kW	—553 lb-ft @ 1300 rpm750 Nm @ 1300 rpm	UN ECE R96 Stage IIIA
1106D-E70TA	—274.9 HP205 kW	—774.4 lb-ft @ 1400 rpm1050 Nm @ 1400 rpm	UN ECE R96 Stage IIIA, Brazil MAR-1, China NRIII
1106C-70TA	—217 HP162 kW	—663 lb-ft @ 1400 rpm900 Nm @ 1400 rpm	EU Stage II/U.S. EPA Tier 2 equivalent
1204J-E44TA	—148 HP110 kW	—413 lb-ft @ 1400 rpm560 Nm @ 1400 rpm	EU Stage V, U.S. EPA & CARB Tier 4 Final
1204EA-E44TA	—148 HP110 kW	—413 lb-ft @ 1400 rpm560 Nm @ 1400 rpm	China NR IV
1204J-E44TTA	—200 HP150 kW	—609 lb-ft @ 1400 rpm825 Nm @ 1400 rpm	EU Stage V, U.S. EPA Tier 4 Final
1204EA-E44TTA	—173 HP129 kW	—553 lb-ft @ 1400 rpm750 Nm @ 1400 rpm	China NR IV
1206J-E70TA	—202 HP151 kW	—642 lb-ft @ 1400 rpm870 Nm @ 1400 rpm	EU Stage V, U.S Tier 4 Final
1206EA-E70TA	—202 HP151 kW	—642 lb-ft @ 1400 rpm870 Nm @ 1400 rpm	China NR IV
1206J-E70TTA	—320 HP239 kW	—935 lb-ft @ 1400 rpm1282 Nm @ 1400 rpm	EU Stage V, U.S. EPA & CARB Tier 4 Final
1206EA-E70TTA	—302 HP225 kW	—940 lb-ft @ 1400 rpm1274 Nm @ 1400 rpm	China NR IV
1706J-E93TA	—456 HP340 kW	—1540 lb-ft @ 1400 rpm2088 Nm @ 1400 rpm	EU Stage V, U.S. EPA Tier 4 Final, Korea Stage V, Japan 2014
1706EA-E93TA	—456 HP340 kW	—1540 lb-ft @ 1400 rpm2088 Nm @ 1400 rpm	China Nonroad Stage IV
1706D-E93TA	—416 HP310 kW	—1335 lb-ft @ 1400 rpm1810 Nm @ 1400 rpm	China Nonroad Stage III, Brazil MAR-1, UN ECE R96 Stage IIIA
2206D-E13TA	—536 HP400 kW	—1735 lb-ft @ 1400 rpm2353 Nm @ 1400 rpm	China Nonroad Stage III, Brazil MAR-1, UN ECE R96 Stage IIIA, U.S. EPA Tier 3
2406J-E13TA	—577 HP430 kW	—1943 lb-ft @ 1400 rpm2634 Nm @ 1400 rpm	EU Stage V, U.S. EPA Tier 4 Final, Japan 2014, Korea tier 4 Final
2406EA-E13TA	—577 HP430 kW	—1943 lb-ft @ 1400 rpm2634 Nm @ 1400 rpm	China NR IV
2506J-E15TA	—581 HP433 kW	—1958 lb-ft @ 1400 rpm2655 Nm @ 1400 rpm	EU Stage V, U.S. EPA & CARB Tier 4 Final
2506EA-E15TA	—580 HP433 kW	—1958 lb-ft @ 1400 rpm2655 Nm @ 1400 rpm	China NR IV
2506D-E15TA	—595 HP444 kW	—2004 lb-ft @ 1400 rpm2717 Nm @ 1400 rpm	EU Stage IIIA/U.S. EPA Tier 3, China NRIII
2806J-E18TA	—630 HP470 kW	—2178 lb-ft @ 1400 rpm2953 Nm @ 1400 rpm	EU Stage V
2806EA-E18TA	—630 HP470 kW	—2177 lb-ft @ 1300 rpm2951 Nm @ 1300 rpm	China NR IV
2806J-E18TTA	—800 HP597 kW	—2734 lb-ft @ 1400 rpm3710 Nm @ 1300 rpm	EU Stage V, U.S. EPA Tier 4 Final
2806D-E18TA	—630 HP470 kW	—2043 lb-ft @ 1400 rpm2769 Nm @ 1400 rpm	UN ECE R96 Stage IIIA, China NRIII
2806D-E18TTA	—800 HP597 kW	—2697 lb-ft @ 1400 rpm3656 Nm @ 1400 rpm	UN ECE R96 Stage IIIA, China NRIII

Benefits & Features

Data not available.
