416F2Non-Current
416F2 - 2014, Tier 4 Final, NACD
Overview
Experience the new Cat 416F2 Backhoe Loader with features including spacious operator station, optional pilot controls, superior durability and outstanding performance. Safely operate on the job site with quieter hydraulics, increased visibility, and the ability to have four wheel braking engaged without wearing on tires or drive train.
Specifications
| Net Power - SAE J1349:2011 | — |
| Dig Depth - Standard | — |
| Operating Weight - Maximum | — |
Benefits & Features
Specifications
| Net Power - SAE J1349:2011 | — |
| Bore | — |
| Stroke | — |
| Displacement | — |
| Net Power - 2,200 rpm - SAE J1349 | — |
| Net Peak Power - 1,800 rpm - EEC 80/1269 | — |
| Net Torque Rise - 1,400 rpm - SAE J1349 | 56% |
| Net Peak Power - 1,800 rpm - ISO 9249 | — |
| Rated Net Power - 2,200 rpm - ISO 9249 | — |
| Gross Power - ISO 14396 | — |
| Net Peak Power - 1,800 rpm - SAE J1349 | — |
| Gross Power - SAE J1995:2014 | — |
| Engine Model | Cat® C4.4 ACERT™ |
| Rated Net Power - 2,200 rpm - EEC 80/1269 | — |
| Note | Engine meets U.S. EPA Tier 4 Final emission standards. |
| Net Peak Torque - 1,400 rpm | — |
| Rated Net Power - SAE J1349 | — |
| Rated Net Power - ISO 9249 | — |
| Operating Weight - Maximum | — |
| Cab - ROPS/FOPS | — |
| Four Wheel Drive | — |
| Counterweights - Option 1 | — |
| Air Conditioning | — |
| Counterweights - Option 2 | — |
| Counterweights - Option 3 | — |
| Operating Weight - Maximum - ROPS Capacity | — |
| MP Bucket (0.96 m3/1.25 yd3) - No Forks or Teeth | — |
| Extendible Stick | — |
| Dig Depth - Standard | — |
| Dig Depth - E-Stick Extended | — |
| Pump Type | Variable Flow, Axial Piston |
| System Pressure - Loader | — |
| Pump Capacity at 2,200 rpm | — |
| System Pressure - Backhoe | — |
| Type | Closed Center |
| Power Shuttle Transmission - Reverse 4th | — |
| Power Shuttle Transmission - Forward 3rd | — |
| Power Shuttle Transmission - Reverse 3rd | — |
| Power Shuttle Transmission - Forward 1st | — |
| Power Shuttle Transmission - Reverse 2nd | — |
| Power Shuttle Transmission - Reverse 1st | — |
| Power Shuttle Transmission - Forward 2nd | — |
| Power Shuttle Transmission - Forward 4th | — |
| Fuel Tank | — |
| Rear Axle | — |
| Diesel Exhaust Fluid (DEF)* | — |
| Rear Axle - Planetaries | — |
| Cooling System with Air Conditioning | — |
| Transmission - Power Shuttle - 2WD | — |
| Front Axle (4WD) - Planetaries | — |
| Engine Oil - With Filter | — |
| Hydraulic System | — |
| Front Axle (4WD) | — |
| Transmission - Power Shuttle - 4WD | — |
| Hydraulic Tank | — |
| Note (1) | Requires ultra-low sulfur fuel less than or equal to 15 ppm fuel sulfur. |
| Note (2) | * Must meet the requirements outlined in ISO 22241. |
| Rear Axle - Dynamic | — |
| Front Axle (2WD) - Static | — |
| Front Axle (2WD) - Dynamic | — |
| Rear Axle - Static | — |
| Front Axle (4WD) - Static | — |
| Front Axle (4WD) - Dynamic | — |
| Cab - ROPS | SAE J1040 MAY94; ISO 3741 1994 |
| Cab - FOPS | SAE J/ISO 3449 APR98 LEVEL II and ISO 3449: 1992 LEVEL II |
| Cab - Sound | ANSI/SAE J1166 OCT98 is 79 dB(A) |
| Brakes | SAE J/ISO 3450; ISO 3450 1996 |
| Exterior Sound | SAE J188 JUN86 is 76 dB(A) |
| Feature (5) | Parking brake is mechanically applied through an adjustable hand lever located on the right console. |
| Feature (2) | Self-adjusting, completely enclosed and sealed. |
| Feature (3) | Foot operated brake pedals can be interlocked for roading. |
| Feature (1) | Brakes meet the following standards: SAE J1473 and ISO 3450 requirements. |
| Feature (4) | Parking/secondary brakes are independent of the service brake system. |
| Feature (8) | Cylinder head is high strength, cast iron alloy construction with extra duty wall and deck thickness. |
| Feature (5) | For durability, inlet valves are nitrided, martensitic chrome silicon steel. |
| Feature (1) | Regeneration is passive and does not require any input from the operator or disrupt work. |
| Feature (12) | Direct electric, 12-volt starting and charging system with 880 CCA Group 31 maintenance free battery. |
| Feature (14) | High contact ratio/gear train, peripheral fixed isolation top cover and open deck block design reduce bare engine noise. |
| Feature (11) | Dry-type axial seal air cleaner with integral precleaner, automatic dust ejection system, and filter condition indicator. |
| Feature (10) | Direct injection fuel system provides accurate fuel delivery and efficiency. |
| Feature (15) | Higher low end torque for better engine/machine performance. |
| Feature (7) | Cylinder block is high strength, cast iron alloy of deep skirt, monobloc design for increased strength and long life. |
| Feature (3) | Forged chrome/molybdenum-steel crankshaft with salt bath nitrocarburized pins and journals. |
| Feature (9) | Cylinder head's intake and exhaust ports are precision cast to promote optimum gas flow. |
| Feature (6) | For durability, exhaust valves are nitrided, austenitic chrome manganese-nickel steel. |
| Feature (16) | Engine is equipped with electric fuel priming pump. |
| Feature (4) | Front and rear crankshaft oil seals are “lip” type Viton and PTFE designs featuring an integral dust lip. |
| Feature (2) | Three-ring pistons made of lightweight, silicon/aluminum alloy for strength and maximum thermal conductivity. |
| Feature (13) | Standard glow plug starting aid system for efficient cold weather starting. |
| Stroke | — |
| Rod Diameter | — |
| Turning Circle - (inner wheel not braked) - Outside Front Wheels | — |
| Axle Oscillation | 11° |
| Bore | — |
| Type | Front Wheel |
| Turning Circle - (inner wheel not braked) - Outside Widest Loader Bucket | — |
| Power Steering | Hydrostatic |
| Choice 2 | Front: 12.5/80-18 (12 ply) 1-3; Rear: 19.5L-24 (12 ply) ATU |
| Choice 3 | Front: 12.5/80-18 NHS (12 ply) 1-3; Rear: 21L-24 (16 ply) R4 ATU |
| Choice 4 | Front: 340/80R18; Rear: 19.5L-24 (12 ply) R4 ATU |
| Choice 1 | Front: 11L-16 (12 ply) F-3; Rear: 19.5L-24 (12 ply) R4 ATU |
Benefits & Features
Operator Station
Unmatched Comfort
- The ergonomic, automotive style operator station helps you work comfortably and productively all day long. Choose the configuration that meets your needs – Canopy, Cab Deluxe or Cab Deluxe with Air Conditioning. Other features include:
- Adjustable air suspension seat
- Tilt and telescoping steering column
- Excellent visibility over hood and up to bucket dump
- Pantograph windshield wiper
- Large front windshield screen
- Large LCD gauge cluster screen
- Ample legroom
- Differential lock button on loader lever
- Large opening windows
- Solid roof cab
- LED brake lights
Ride Control
The optional Ride Control System smoothes the ride in all conditions, including load and carry, highway roading or simply moving around the job site. The result can be increased operator comfort, potentially reducing operator fatigue, and improved material retention.
Premium Gauge Cluster
Bright and large LCD screen makes it easy to monitor machine operation and settings. LED indicator lights and audible alarms allow the machine to clearly communicate with the operator.
Safety Getting in and out of the Cab
New longer grab handles and ergonomic step placement makes it easy to maintain three points of contact when getting in and out of the cab.
Backhoe Controls
Mechanical controls provide the feedback operators look for in trenching applications. Low effort hydraulics reduce operator fatigue while maintaining performance. Optional joystick controls allow the operator to customize the pod location and control pattern.
Power Train
Cat Engine
- The Cat C4.4 ACERT engine operates quietly while delivering performance and durability. The engine meets U.S. EPA Tier 4 Final emission standards. Engine features include:
- Selective catalytic reduction
- Diesel oxidation catalyst
- Diesel exhaust fluid with system purge
- Limited operator interaction
Transmission
- The standard power shuttle transmission provides four speeds forward and reverse. Hydraulically shifted clutches allow on-the-go direction and travel speed shifts.
- Hydraulic proportional control valves deliver smooth speed and directional shifts.
- Four Wheel Drive option improves mobility and loader performance in poor underfoot conditions and can be activated on-the-go.
Brake Mode Selector
Brake mode selector switch has three positions: two wheel drive, two wheel drive with all wheel braking and four wheel drive. Two wheel drive with all wheel braking provides better tire life while roading and engages the front axle when brakes are applied for improved braking performance. Brake mode selector is included in the 4WD package.
Advanced Hydraulics
Load Sensing Hydraulics
- Closed center hydraulic system matches pressure and flow to application demand. Whether you're in full trenching mode or digging around delicate services, you remain in control. In applications such as production trenching where speed is important, the system will provide the flow needed to get the job done quickly and efficiently. The load sensing hydraulic system provides:
- Better fuel efficiency
- Quieter operation
- Reduced component wear
- Cooler hydraulic temperatures
- Full forces at any engine speed
Flow Sharing Valves
Specifically tuned hydraulic valves allow for the multifunction of hydraulic components, without machine manipulation. Hydraulic fluid is shared between implements so that operation isn't interrupted.
Hydraulic Lines
Combination two way and one way flow hydraulic lines add versatility to the machine. By simply changing the lever position, the machine can efficiently run either style hydro mechanical tool.
Backhoe Performance
Boom
The excavator-style boom is built for optimum performance and durability. The curved design provides added clearance when digging over obstacles or loading trucks. The narrow boom enhances the viewing area to the bucket and the trench throughout the operating range. More robust swing casting and double clevis design improves durability and reliability.
Stick
Serrated edges on the stick provide improved material clamping for clearing and demolition applications. The optional extendible stick (E-stick) increases reach and dig depth by approximately 1.2 m (4 ft).
Thumbs
Thumb mounting provisions are standard on every Cat Backhoe Loader for added machine versatility. Cat hydraulic thumbs are available for even greater versatility. Mechanical thumbs are also available through your Cat dealer.
Loader Performance
Front loader arms deliver more reach, dump height and breakout.
Single Tilt
The standard single tilt loader linkage features strong lift and breakout forces for solid performance in backfilling and truck loading applications with pin-on buckets. The 416F2 is equipped with either a general purpose or multi-purpose pin-on bucket to meet your specific needs.
Return-to-Dig
The return-to-dig system reduces loading cycle times by bringing the loader bucket back to the dig position with an easy pull of the lever. By the time the loader bucket is at ground level, the bucket is angled correctly for the next load or cut.
Work Tools
Backhoe Work Tools
- Increase the versatility of your machine with the large selection of backhoe attachments:
- Buckets – Standard Duty, Heavy Duty, Heavy Duty Rock, Soil Excavation, Coral and Ditch Cleaning
- Cold Planers
- Hammers
- Augers
- Rippers
- Thumbs (mechanical and hydraulic)
- Vibratory Plate Compactors
- Quick Couplers
Loader Work Tools
- A wide range of loader attachments is available including:
- General Purpose Bucket
- Multi Purpose Bucket
- Side Dump Bucket
- Forks
Diagonal Retention System
Heavy duty bucket teeth are attached with diagonal pins rather than horizontal pins for easy exchange without the use of special tools.
Backhoe Quick Coupler
Manual or hydraulic backhoe couplers make rear tool exchange quick and easy. New Cat dual lock coupler has a self-adjusting wedge design to ensure a tight fit. It also features a safety lock that automatically engages.
Serviceability
Minimize Your Downtime
- Convenient service features make maintenance easy, reducing your downtime:
- Hinged cooling pack provides easy access
- Tilt up hood provides easy, convenient access to all engine check points
- Engine side panels remove easily without the use of tools
- Cat Product Link™ system (optional) provides remote reporting of machine location and operating system parameters
Customer Support
Renowned Dealer Support
- From helping you choose the right machine to knowledgeable ongoing support, Cat dealers provide the best in sales and service.
- Preventive maintenance programs and guaranteed maintenance contracts
- Best-in-class parts availability
- Operator training to help boost your profits
- Genuine Cat Remanufactured parts
