D6T

D6T [2012] S Am

Overview

The Cat D6T dozer has earned a reputation for best-in-class versatility, productivity and resale value. Because it excels across a wide range of dozing tasks, customers choose the D6T for everything from dozing, ripping, scraper work and land clearing to finish grading, backfilling trenches, building oil/gas/wind farm pads and working landfills. The D6T offers many of the robust features found on larger tractors, with the reliability and low operating costs customers have come to expect from Cat Track-Type Tractors.

Specifications

Units:
Engine Model Cat C9
Power - Net —
Operating Weight —
See more

Benefits & Features

OPERATOR COMFORT AND CONTROL

    • Cab designed for operator productivity and comfort.
    • Isolation-mounted, pressurized cab reduces noise and vibration.
    • Large windows, tapered hood, notched fuel tank and narrow single-shank ripper carriage give the operator a clear line of sight to front and rear work areas.
    • Cat comfort series seat is well padded and adjustable; bolsters help support the operator during slope work.
    • Radio ready and equipped with a power converter for cellular phones and computers.
    • Single steering tiller helps operators work more precisely in tight areas.
    • Decelerator pedal gives the operator full control of engine speed when the rocker switch is in the high idle position.
    • Auto-shift/auto kickdown allows the transmission to automatically downshift under large load.

PERFORMANCE AND PRODUCTIVITY

    • Components are carefully designed to maximize long term value, durability and reliability.
    • Powershift transmission and differential steering work in tandem with the Cat C9 engine to deliver outstanding power, productive performance and reliability.
    • Dual hydraulic pump system provides dedicated hydraulic power to steering and implements for outstanding steering performance and response.
    • Differential steering maintains full power to both tracks, providing best in class turning with a loaded blade or in soft ground conditions.
    • A single-stage torque divider delivers more power to the ground.
    • Durable, efficient cooling system uses aluminum bar plate construction for performance and durability.

BUILT FOR LONG TERM PRODUCTION

    • Elevated sprocket design isolates final drives, axles, and steering components from harsh impacts.
    • Wide variety of undercarriage and track shoe choices to optimize performance and undercarriage life in your specific conditions.
    • The foundation of every Cat dozer is a rugged frame built to absorb high impact shock loads and twisting forces.
    • Pinned equalizer bar gives the roller frames the ability to oscillate up and down to better match ground contours maximizing traction and operator comfort.

See more
  November 6, 2024

Specifications

Units:
Engine
Engine Model Cat C9
Power - Net —
Emissions Brazil MAR-1, equivalent to U.S. EPA Tier 3/EU Stage IIIA
Engine Power - STD
Net Power - ISO 9249 —
Engine - STD
Note (1) Engine ratings apply at 1,850 rpm. Net power advertised is the power available at the flywheel when engine is equipped with a fan at maximum speed, air cleaner, muffler and alternator. Advertised power is tested per the specified standard in effect at the time of manufacture.
Engine Power - XL/LGP
Net Power - ISO 9249 —
Engine - XL/LGP
Note (1) Engine ratings apply at 1,850 rpm. Net power advertised is the power available at the flywheel when engine is equipped with a fan at maximum speed, air cleaner, muffler and alternator. Advertised power is tested per the specified standard in effect at the time of manufacture.
Service Refill Capacities
Fuel Tank —
Weights
Operating Weight —
Operating Weight - STD A-Blade —
Operating Weight - STD SU-Blade —
Operating Weight - XL A-Blade —
Operating Weight - XL SU-Blade —
Operating Weight - LGP S-Blade —
Note (1) Operating Weight includes blade, lubricants, coolant, full fuel tank, standard track, ROPS/FOPS cab, drawbar and operator.
Blades
S-Blade Capacity - LGP —
SU - Blade Capacity —
SU XL - Capacity —
A-Blade Capacity —
A XL - Capacity —
S-Blade Width - LGP —
SU - Blade Width —
SU XL - Width —
A-Blade Width —
A XL - Width —

Benefits & Features

OPERATOR COMFORT AND CONTROL

    • Cab designed for operator productivity and comfort.
    • Isolation-mounted, pressurized cab reduces noise and vibration.
    • Large windows, tapered hood, notched fuel tank and narrow single-shank ripper carriage give the operator a clear line of sight to front and rear work areas.
    • Cat comfort series seat is well padded and adjustable; bolsters help support the operator during slope work.
    • Radio ready and equipped with a power converter for cellular phones and computers.
    • Single steering tiller helps operators work more precisely in tight areas.
    • Decelerator pedal gives the operator full control of engine speed when the rocker switch is in the high idle position.
    • Auto-shift/auto kickdown allows the transmission to automatically downshift under large load.

PERFORMANCE AND PRODUCTIVITY

    • Components are carefully designed to maximize long term value, durability and reliability.
    • Powershift transmission and differential steering work in tandem with the Cat C9 engine to deliver outstanding power, productive performance and reliability.
    • Dual hydraulic pump system provides dedicated hydraulic power to steering and implements for outstanding steering performance and response.
    • Differential steering maintains full power to both tracks, providing best in class turning with a loaded blade or in soft ground conditions.
    • A single-stage torque divider delivers more power to the ground.
    • Durable, efficient cooling system uses aluminum bar plate construction for performance and durability.

BUILT FOR LONG TERM PRODUCTION

    • Elevated sprocket design isolates final drives, axles, and steering components from harsh impacts.
    • Wide variety of undercarriage and track shoe choices to optimize performance and undercarriage life in your specific conditions.
    • The foundation of every Cat dozer is a rugged frame built to absorb high impact shock loads and twisting forces.
    • Pinned equalizer bar gives the roller frames the ability to oscillate up and down to better match ground contours maximizing traction and operator comfort.

BUILT TO PERFORM

    • L-shaped push arms bring the blade closer to the machine for excellent maneuverability, balance and blade penetration.
    • Load-sensing hydraulics are responsive, automatically and continually adjusting hydraulic power to maximize efficiency and blade response.
    • Blades feature heavy moldboard construction and hardened bolt-on cutting edges/end bits for strength and durability.
    • Choose from a variety of rear attachments to optimize your dozer for the work you do.

LOWER MAINTENANCE COSTS

    • Service access is easy with conveniently located, grouped service points and wide engine compartment access panels to helping reduce maintenance time.
    • Power train oil filter and pressure taps are remote-mounted in the right-hand fender. Quick disconnect fittings allow for fast diagnosis of the power train and hydraulic oil systems.
    • Engine oil filter is easily accessed on the right side of the engine compartment. An optional quick oil change attachment can further reduce maintenance time.
    • The modular design aids serviceability to help reduce maintenance costs.
    • Remote lubrication point in the engine compartment provides easy lubrication of the center pin of the equalizer bar as part of scheduled maintenance.
    • Product Link™ collects machine data that can be viewed online through web and mobile applications.
    • Access information anytime, anywhere with VisionLink® and use it to make informed decisions that boost productivity, lower costs, simplify maintenance, and improve security on your job site.

TECHNOLOGY THAT GETS WORK DONE

    • AccuGrade uses positioning and guidance technologies, machine sensors, and automatic blade control to help operators get to grade faster, easier and more efficiently.
    • Digital design plans, real-time cut/fill data, and in-cab guidance give operators detailed information to work more confidently and achieve greater accuracy, in fewer passes, using less material.
    • Operators can stay on grade and improve productivity and accuracy by nearly 50 percent over conventional methods.
    • Grade stakes and checkers are minimized, making the work site safe, efficient, and cost effective. AccuGrade technologies include Cross Slope, Sonic, Laser, GPS, and/or Universal Total Station (UTS).
    • All Cat Grade systems are compatible with radios and base stations from Trimble, Topcon, and Leica.
    • Already invested in a grade infrastructure? You can install grade systems from Trimble, Topcon, and Leica onto the machine.

PURPOSE BUILT SPECIALTY MODELS

    • Waste Handler/Landfill Arrangement offers specialized guarding, striker bars and seals help protect the machine from impact and airborne/wrapping debris. Cooling is designed for high debris environments and easy cleanout. Specialized air handling features help deliver cleaner air to the machine. Landfill blades and center-hole track shoes help optimize your waste handler for the job.
    • Equip your machine for Forestry work, choosing optional sweeps, screens and added guarding to help protect the machine in harsh conditions.

Standard Equipment

  • NOTE
    • Standard and optional equipment may vary. Consult your Cat dealer for details.
  • POWER TRAIN
    • C9 diesel engine
    • Radiator, Aluminum Bar Plate
    • Air cleaner, precleaner with stratta tube dust ejector
    • Air filter with electronic service indicator
    • Aftercooler, air to air (ATAAC)
    • Coolant, extended life
    • Fan, blower, direct drive
    • Final drives, three planet single reduction planetary
    • Fuel priming pump, electric
    • Muffler, insulated with mitered stack
    • Parking brake, electronic
    • Prescreener
    • Shift management: – Automatic directional and downshift – Controlled throttle, load compensated
    • Starting aid, ether, automatic
    • Torque divider
    • Transmission, electronically controlled powershift 3F/3R speeds
    • Turbocharger, wastegate
    • Water separator
  • UNDERCARRIAGE
    • Cat Abrasion
    • Carrier rollers
    • Equalizer bar, heavy duty
    • Guards, end track guiding
    • Idlers, center tread, lifetime lubricated
    • Rollers, lifetime lubricated track
    • Track roller frames, tubular
    • Track adjusters, hydraulic
    • Sprocket rim segments, replaceable
  • ELECTRICAL
    • Alarm, backup
    • Alternator, 95 amp, brushless
    • Batteries, 2 maintenance free 12V (24V system), heavy duty
    • Converter, 12V, 10 amp with 2 outlets
    • Connector, diagnostic
    • Electric start, 24V
    • Horn, forward warning
  • OPERATOR ENVIRONMENT
    • Air conditioner, underhood
    • Armrest, adjustable
    • Cab, ROPS/FOPS, sound suppressed
    • Decelerator pedal
    • Differential steering control with touch shift
    • Electronic Monitoring System with coolant power train oil, and hydraulic oil temperature, fuel gauge, tachometer, odometer, gear indicator and diagnostic functions
    • Foot pads, dash
    • Heater
    • Hour meter, electronic
    • Hydraulic controls, pilot operated with electronic deactivation switch
    • Mirror, rearview
    • Radio ready
    • Seat, adjustable contour suspension
    • Seatbelt, retractable 76 mm (3 in)
    • Throttle switch, electronic
    • Wipers, intermittent
  • CAT TECHNOLOGY
    • Compatibility with radios and base stations from Trimble, Topcon, and Leica
    • Capability to install 3D grade systems from Trimble, Topcon, and Leica
  • OTHER STANDARD EQUIPMENT
    • CD ROM Parts Book
    • Engine enclosures, perforated
    • Front pull device
    • Guards, hinged bottom
    • Hood, perforated
    • Hydrualics, independent steering and work tool pumps
    • Hydraulics, load sensing, dozer lift and tilt
    • Oil cooler, hydraulic
    • Product link ready
    • Radiator doors, louvered, hinged, fan blast deflector
    • S·O·S sampling ports
    • Tool box
    • Vandalism protection for fluid compartments and battery box

Optional Equipment

  • NOTE
    • Standard and optional equipment may vary. Consult your Cat dealer for details.
  • POWER TRAIN
    • Drains, ecology, power train
    • Prescreener
    • Grid, radiator core protector
    • Fan, ejector
    • Fan, reversible
    • Precleaner, turbine with screen
    • Precleaner, turbine without screen
    • Thermal shield arrangement
  • UNDERCARRIAGE
    • Undercarriage, Heavy Duty
    • Track pairs (Standard roller frame, 39 section): – Extreme Service (HD) 560 mm (22 in) – Extreme Service (Cat Abrasion) 560 mm (22 in) – Non-Trapezoidal (Cat Abrasion) 610 mm (24 in) – Moderate Service (HD) 560 mm (22 in) – Moderate Service (Cat Abrasion) 610 mm (24 in)
    • Track pairs (XL non-VPAT roller frame, 41 section): – Extreme Service (HD) 560 mm (22 in) – Extreme Service (HD) 610 mm (24 in), non-trapezoidal – Extreme Service (Cat Abrasion) 560 mm (22 in) – Extreme Service (Cat Abrasion) 610 mm (24 in), non-trapezoidal – Moderate Service (HD) 610 mm (24 in) – Extreme Service (HD) 610 mm (24 in), trapezoidal – Extreme Service (Cat Abrasion) 560 mm (22 in), center hole
  • HYDRAULICS
    • Hydraulics, ripper
  • STARTERS, BATTERIES AND ALTERNATORS
    • Alternator, 150 amp
    • Alternator, 95 amp, ducted
    • Heater, engine coolant, 120V
    • Batteries, heavy duty and starter
  • ELECTRICAL
    • Lights, five
    • Lights, seven
    • Lights, eleven
    • Lights, sweeps
    • Light, warning strobe
    • Switch, disconnect, remote mounted
  • OPERATOR ENVIRONMENT
    • Air conditioner, ROPS mounted
    • Canopy
    • Seat, vinyl
    • Camera, rear vision
    • Cab, arrangement with screens
    • Glass, dual pane and precleaner
    • Handles, heavy duty
  • CAT TECHNOLOGY
    • Security system, machine
  • TECHNOLOGY PRODUCTS
    • AccuGrade ready, cab
    • Blade groups with AccuGrade mounts
  • GUARDS
    • Note: Additional guarding may be required for some tractor applications
    • Idler seals
    • Heavy duty crankcase guard
    • Hinged radiator guard
    • Metal hose protection sleeve
    • Clamshell final drive
    • Final drive seals
    • Fuel tank guard
    • Precleaner
    • Heavy duty radiator
    • Hinged heavy duty radiator
    • Rear tractor guard
    • Rear screen
    • Forestry guarding
    • Moderate service track guard
    • Full length track guard
    • Full track guard
    • Striker bars: front and rear
    • Striker bar box, rear
  • COUNTERWEIGHTS AND DRAWBARS
    • Counterweight, additional
    • Counterweight, rear slab
    • Counterweight, rigid short
  • WINCH
    • Please see your Cat dealer for Winch options
  • MISCELLANEOUS
    • Paint, black hood and cylinders
    • Sweeps
  • BLADES
    • 6SU
    • 6S
    • 6A
    • Blade, Landfill, 6SU
  • GROUND ENGAGING TOOLS
    • Ripper, multi-shank
    • Tooth, multi-shank ripper
    • Tooth, straight (1, 2 or 3)
