Specifications
Units:
| Continuous Rating | 800 ekW |
| Fuel Type | Natural Gas, Biogas, Coal Gas |
| Maximum Electrical Efficiency | 42.50% |
| Maximum Standby Rating | - |
| Frequency | 50/60Hz |
| RPM | 1500 / 1800 rpm |
| Stroke | — |
| Bore | — |
| Aspiration | TA |
| Displacement | — |
| Engine Model | CG132 |
| Length | — |
| Width | — |
| Height | — |
| Dry Weight - Genset | — |
Benefits & Features
Lower Operating Costs
Lower Operating Costs
- Optimized engine components mean the CG132 uses up to 50 percent less lubricating oil than competing generator sets, which means more money stays in your company's pockets
Smaller footprint
Smaller footprint
- The CG132 uses nearly 50 percent less space than similar system
- Less space means lower installation costs
Cat Electronic Control System
Cat Total Electronic Management System
- Temperature and pressure monitoring for each cylinder
- Anti-knock control allow for maximum power output and the best possible fuel utilization, even if gas composition changes
Flexible Fuel Usage
Flexible Fuel Usage
- Our gas-mixer technology and Total Electronic Management System let you use a wide variety of gases, including problematic gases like digester, landfill and sewage gases
Data not available.
Standard Equipment
- Air Inlet
- Turbocharger for the CG132-8 with a water-cooled bearing case
- Two-element single-stage air cleaner with enclosure and service indicator
- Control Panels
- TEM (Total Electronic Management)
- Exhaust
- Closed crankcase ventilation system
- PEARL/Low resistence exhaust system
- Cooling
- Cat flanges on SCAC circuit
- Jacket water and SCAC thermostats
- Engine driven water pumps for jacket water and after cooler
- Electrical jacket water and aftercooler coolant pump
- Cat flanges on SCAC circuit
- ANSI/DN customer flange connections for JW inlet and outlet
- Flange connections for JW inlet and outlet
- Fuel system
- Electronic fuel metering valve
- Pre-chamber spark plugs
- Independently controlled cylinder monitoring and ignition system
- Generator
- 3-phase sensing and KVAR/PF control
- Reactive droop
- Anti-condensation space heater
- Winding temperature detectors
- Busbar connections
- Starting/Charging
- 24V starting motors
- Battery disconnect switch
- General
- Crankshaft vibration damper and guard
Optional Equipment
- Air Inlet
- Mounting stand
- Air cleaner with precleaner
- Cooling
- CHP skid
