Specifications
| Minimum Rating | 320 ekW |
| Maximum Rating | 400 ekW |
| Emissions/Fuel Strategy | EPA Stat Emergency Use |
| Voltage | 208 to 600 Volts |
| Frequency | 60 Hz |
| Speed | 1800 rpm |
| Engine Model | C13 ACERT In-line 6, 4-cycle diesel |
| Compression Ratio | 16.3:1 |
| Aspiration | Turbocharged Air to Air Aftercooled |
| Governor Type | Adem™A4 |
| Fuel System | MEUI |
| Stroke | — |
| Displacement | — |
| Bore | — |
Benefits & Features
Cat Diesel Engine
Cat Diesel Engine
- Reliable, rugged, durable design
- Field-proven in thousands of applications worldwide
- Four-stroke-cycle diesel engine combines consistent performance and excellent fuel economy with minimum weight
Generator
Generator
- Matched to the performance and output characteristics of Cat engines
- Industry leading mechanical and electrical design
- Industry leading motor starting capabilities
- High Efficiency
EMCP Control Panel
EMCP Control Panel
The EMCP controller features the reliability and durability you have come to expect from your Cat equipment. EMCP4 is a scalable control platform designed to ensure reliable generator set operation, providing extensive information about power output and engine operation. EMCP4 systems can be further customized to meet your needs through programming and expansion modules.
Design Criteria
Design Criteria
The generator set accepts 100% rated load in one step per NFPA 110 and meets ISO 8528-5 transient response.
Single-Source Supplier
Single-Source Supplier
Fully prototype tested with certified torsional vibration analysis available
World Wide Product Support
World Wide Product Support
Cat dealers provide extensive post-sale support including maintenance and repair agreements. Cat dealers have over 1,800 dealer branch stores operating in 200 countries. The Caterpillar S•O•S℠ program cost effectively detects internal engine component condition, even the presence of unwanted fluids and combustion by-products
Data not available.
Standard Equipment
- Starting / Charging
- Charging alternator
- 24-Volt electric starting motor
- Control System Controller
- EMCP 4.2
- Certification
- EPA stationary emergency use
- Base / Fuel Tank
- Audio and visual fuel alarm
- Protection
- Coolant level sensor
- Safety shutoff - Low oil pressure
- Safety shutoff - High water temperature
- Safety shutoff - Overspeed
Optional Equipment
- Engine air cleaner
- Single Element
- Dual element
- Heavy duty
- Muffler
- Industrial grade (10 dBA)
- Residential and critical grade (25 dBA)
- Starting and Charging
- Standard battery set
- Oversize battery set
- Control System Controller
- EMCP 4.4
- Local annunciator
- Remote annunciator module
- Discrete I/O module
- Device Server
- Volt free contact
- Earth (ground) fault relay
- Generator
- Excitation - Self
- Excitation - Internal/AREP
- Excitation - PMG
- Oversize
- Coastal protection (CIP)
- Space heater control
- Output Voltages
- Power Termination
- Power terminal strip
- Circuit breakers
- Enclosure
- Weather protective
- Sound attenuated
- Certification
- UL2200 listed
- CSA 22.2
- Certification of Compliance - IBC Seismic
- Certification of Compliance - IBC Seismic and OSHPD
- Extended Service Coverage
- 2 Year
- 3 Year
- 4 Year
- 5 Year
- 10 Year
- Base / Fuel Tank
- Narrow skid base
- Wide / Standard
- Sub tank base - UL and ULC listed
- Integral tank base, UL AND ULC listed
- Spill containment
- Overfill prevention valve
